| 1/3" Progressive Scan CMOS |
Image Sensor |
| 0.5Lux @(F1.6, AGC ON), 0 Lux with IR |
Minimum Illumination |
| Self-adaptive shutter |
Shutter Speed |
Top: 2.8mm @ F1.6, Diagonal: 110°, Horizontal: 96°, Vertical: 54°
Bottom: 6mm @ F1.6, Diagonal: 60°, Horizontal 52°, Vertical 28° |
Lens |
Top Lens: Pan: 220°, Tilt: 10° (manual adjustment for vertical angle)
Bottom Lens: Pan: 324°, Tilt: 90° |
PT Angle |
| M12 |
Lens Mount |
| IR-cut filter with auto switch |
Day & Night |
| 3D DNR |
DNR |
| Digital WDR |
WDR |
| IR Distance: 30m, Color Night Vision Distance: Up to 40m (when two lenses point in the same direction) |
Night Vision |
| (2K+ (2560x1440 |
Max Resolution |
| Self-adaptive during network transmission |
Frame Rate |
| H.265 / H.264 |
Video Compression |
| Main Profile |
H.265 Type |
Video: Quad HD; Full HD; Standard adaptive bit rate
Audio: Self-Adaptive |
Bit Rate |
| IEEE802.11b, 802.11g, 802.11n |
Wi-Fi standard |
| 2.4GHz ~ 2.4835 GHz |
Frequency Range |
| Supports 20MHz |
Channel Bandwidth |
| WPA-PSK / WPA2-PSK |
Network Security |
| 11b: 11Mbps, 11g: 54Mbps, 11n: 150Mbps |
Transmission Rate |
| AP pairing |
Wi-Fi Pairing |
| EZVIZ Cloud Proprietary Protocol |
Protocol |
| RJ45 x1 (10M/100M Adaptive Ethernet Port) |
Wired Network |
AI-Powered Human Shape Detection
AI-Powered Vehicle Shape Detection
Motion Detection |
Smart Alarm |
| Supports |
Auto Tracking |
| Supports |
Customized Alert Area |
| Supports |
Two-way Talk |
| Supports |
Preset Locations |
| Anti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark |
General Function |
Local: Supports microSD card (Up to 512GB)
Cloud: Supports EZVIZ CloudPlay storage (Subscription required) |
Storage |
| Temperature: -30°C~50°C, Humidity: 95% or less (non-condensing) |
Operating Conditions |
| Weatherproof Design IP65 + 2h rainstorm |
IP Grade |
| DC 12V/1.5A |
Power Supply |
| Max. 18W |
Power Consumption |
| 224x135x136 mm |
Dimensions |
Net Weight: 723g
|
Weight |
| H90 Dual 2K+ Camera, Power Adapter, Drill Template, Waterproof Kit, Screw Kit, Quick Start Guide |
In the box |
| CE / UL / REACH / WEEE / RoHS |
Certifications |
