| Yes |
NDAA Compliant |
| H.265 (HEVC) / H.264 |
Compression Format |
| Yes (For IP Channels) |
ONVIF |
| All in 1 Hybrid (AHD / CVI / TVI / CVBS + IP) |
Format |
Max. IP: 24CH Standard BNC + 16CH IP (Over Network)
Max.Analog: 32CH Standard BNC + 8CH IP (Over Network) - Default Setting
|
Video Input |
| HDMI (1920x1080), VGA (1280x1024, 1024x768), CVBS (Spot) |
Video Standard Output |
Two Way Audio
Input: 4CH RCA (2.0 Vp-p, 1kΩ)(+IP Cameras)
Output: 1CH RCA ( 2.0 Vp-p, 1kΩ) (+IP Cameras) |
Audio |
AHD / TVI: 5MP Lite: Up to 10FPS Per Channel, 4MP Lite / 2MP: Up to 12/15FPS Per Channel, 2MP Lite / 1MP: Up to 25/30 FPS Per Channel
CVI: 4MP Lite / 2MP: Up to 12/15FPS Per Channel, 2MP Lite / 1MP: Up to 25/30FPS Per Channel
CVBS: 960H: Up to 30/25 FPS Per Channel
IP: 5MP and lower: 25/30FPS Per Channel
Master Streams over Network: Up to 16Ch@Recording Resolution (Up to 160Mbps) |
Main Stream |
HD Analog: 1-25/30FPS@1080P Per Channel (FPS Restricted to Master Stream FPS)
CVBS / IP: 1-25/30FPS@D1 Per Channel
IP: 1-25/30FPS@D1 Per Channel
Over Network: Restricted to 160Mbps |
Sub Stream |
User Access: 5 Users Online with Professional Authority Management
Applications: Provision CAM2 for iOS/Android, IE for Windows 7/8/10, Safari for Mac OS, CMS for Windows/MAC
|
Remote Application |
| Schedule, Manual, Motion, Sensor, Analytics, POS |
Recording Modes |
Incoming: 40Mbps
Outgoing: 160Mbps |
Bandwidth |
Local / Remote: 16CH / 8CH
Search Mode: Time-Slice, Time, Event, File Management, Smart Search |
Playback |
For HD Analog Cameras: Line
Crossing (No Direction Choice), Sterile Area
For IP Cameras: Line Crossing (With Direction Choice), Sterile Area, Item Monitoring, Camera Tampering, Smart Search |
Analytics |
1USB 2.0 Port + 1USB 3.0 Port
Backup Format: AVI/DAT |
Backup |
Alarm-In: 4 (+IP Cameras)
Alarm-Out: 1 (+IP Cameras)
|
Alarm (Input/Output) |
HDD: 4 SATA (Up to 10TB) with smart management
E-SATA: 1 E-SATA (Up to 10TB) |
Storage |
Connection: CoC / IP-Over Network
Supported Protocols: Pelco D, Pelco P, Samsung, Visca, ONVIF, CoC
Supported Controls: Pan, Tilt, Zoom, Preset, Cruise, Scan, Iris, Focus |
PTZ |
Ethernet: 1000 Mbps (RJ-45)
Protocols: TCP/IP, DHCP, DDNS, NTP, SMTP, RTSP, HTTPS, FTP, SNMP, P2P, POS |
Network |
| 440x390x80 mm |
Dimension (W*D*H) |
| AC 110V/220V |
Power Supply |
| 0°C~50°C |
Operation Temperature |
