| H.265 (HEVC) / H.264 |
Video Compression |
| G.711u |
Audio Compression |
| IP Channels Only |
ONVIF |
| All in 1 Hybrid (AHD / CVI / TVI / CVBS + IP) |
Format |
| 4CH Standard BNC + 2CH IP (over Network) |
Video Input |
| HDMI (4K, 1920x1080), VGA (1280x1024), CVBS(Spot) |
Video Output |
Two Way Audio
Input: 1CH RCA (2.0 Vp-p, 1kΩ)(+IP Cameras)
Output: 1CH RCA ( 2.0 Vp-p, 1kΩ) |
Audio |
IP: 8MP 20FPS Per Channel, 5MP and
lower 25/30FPS Per Channel
AHD / TVI: 8MP lite / 5MP / 4MP: Up to 12/15FPS Per Channel, 5MP Lite Up to 20FPS Per Channel, 4MP lite / 2MP / 1MP: Up to 25/30FPS Per Channel
CVI: 4MP Up to 12/15FPS Per Channel, 2MP / 1MP: Up to 25/30FPS
Per Channel
CVBS: 960H: Up to 25/30FPS Per Channel
Master Stream Over Network: 8Ch |
Main Resolution & FPS |
IP: 1-25/30 FPS@D1 Per Channel
HD Analog: 1-25/30 FPS@1080P Per Channel
CVBS: 1-25/30 FPS @D1 Per Channel
over Network: Up to Outgoing Bandwidth Capacity |
Network (Sub-Stream) Resolution & FPS |
Schedule, Manual, Motion, Sensor, Analytics, POS
|
Recording Modes |
Local / Remote: 4CH / 6CH
Search Mode: Time-Slice, Time, Event, File Management, Smart Search |
Playback |
2xUSB 2.0 Port
Backup Format: AVI/DAT |
Backup |
Plug-in free Web-Browser: Chrome, FireFox, Safari, Edge, Opera (All Limited to 4Ch Live View / Playback)
PC/Mac Software: Ossia VMS Standard / Enterprise
Plug-in based Web-Browser: Internet Explorer
Mobile Application: Provision Cam2 for iOS/ Android
User Access: 5 Users Online with Professional Autorithy Management |
Remote Application |
Yes (Pixel Based)
For AHD Cameras: Line Crossing (No Direction Choice), Sterile Area, Smart Search
For IP Cameras: Line Crossing (With Direction Choice), Sterile Area, Item Monitoring, Camera Tampering, Smart Search |
Analytics |
Alarm-in / Alarm-Out: IP Cameras only
Alarm Box Support: No |
Alarm |
| HDD: 1 SATA (Up to 6TB) |
Storage |
Connection: RS-485 / CoC / IP-Over Network
Supported Protocols: Pelco D, Pelco P, Samsung, Visca, ONVIF, CoC
Supported Controls: Pan, Tilt, Zoom, Preset, Cruise, Scan, Iris, Focus |
PTZ |
Ethernet: 100Mbps (RJ-45)
Protocol: TCP/IP, DHCP, DDNS, NTP, SMTP, RTSP, HTTPS, FTP, SNMP, P2P, POS
Bandwidth: Incoming: 16Mbps Outgoing: 40Mbps |
Network |
| 255x220x43 mm |
Dimension (W*D*H) |
| 12V/2A |
Power Supply |
| 0°C~50°C |
Operation Temperature |
