| Up to 12 IP cameras |
IP Video Input |
| Cameras with built-in mic |
Audio Input |
| VGA, HDMI |
Video Output |
|
HDMI: 3840x2160, 1920x1080, 1280x1024, 1280x720, 1024x768
VGA: 1920x1080, 1280x1024, 1280x720, 1024x768
|
Display Resolution |
|
1channel, RCA
|
Audio output |
|
H.264, H.265
|
Video Format |
| 7680x2160, 4608x1728, 4512x2512, 4096x3072, 3840x2160, 2560x2560, 2560x1920, 2560x1440, 2048x1536, 2304x1296, 1080p, 720p |
Live View / Playback Resolution |
| Up to 4 channels |
Synchronous Playback |
SATA: 1x SATA interface (1x 2TB HDD included)
Capacity: Up to 16TB
|
HDD |
2x USB2.0
|
USB Interface |
1x RJ-45 10/100 Mbps self-adaptive (for LAN/WAN)
4x RJ-45 10/100 Mbps self-adaptive for IP cameras |
Network Interface |
Wireless Standard: IEEE 802.11 a/ac/ax/b/g/n
Operating Frequency: 2.4GHz / 5GHz
Wireless Security: WPA / WPA2 / WPA3 |
Wi-Fi |
| HTTPS, TCP/IP, UDP, DHCP, P2P, UPNP, RTMP, RTSP, SMTP, SSL/TLS, DNS, DDNS, NTP, FTP |
Network Protocols |
| Edge, Firefox, Chrome, Safari |
Browsers Supported |
| PC: Windows, Mac OS; Smartphone: iOS, Android |
OS Supported |
| Supports up to 12 simultaneous video streams (10 substreams & 2 mainstreams); 20 users (1 admin account & 19 user accounts) |
Maximal User Access |
| DC 12V/2A |
Power Supply |
| 10W (with 2TB HDD)> |
Power Consumption |
Temperature: -10°C~45°C
Humidity: 10%~90% |
Working Environment |
255x49.5x222.7 mm
|
Dimensions |
| 1.4kg |
Weight |
