Main Processor ARM Cortex A7 Processor
Operating System Embedded Linux |
System |
| 8Ch (8MP / 6MP / 5MP / 4MP / 3MP / 1080p / 1280x1024 / 960p / 720p / D1 / CIF) |
Video Input |
| 1x HDMI |
Video Output |
| 64Kbps |
Audio Bit Rate |
| G711U, G711A |
Audio Compression |
| Motion Detection 8 Channel, MD Zones: 396 (22x18), Trigger Events Recording, Email, FTP, Snapshot and Screen Tips |
Alarm |
| 1920x1080 / 1280x1024 / 1280x720 / 1024x768 |
HD Output |
| 8Ch / 6Ch / 4Ch / 1Ch |
Display Split |
| Yes |
Digital Zoom |
| Camera Title, Time, Recording, Motion Detection, Event Alarm |
OSD |
| H.265+ / H.264+ / H.264 / H.265 |
Video Compression |
PAL: 4K and lower @ 8Ch x 25fps
NTSC: 4K and lower @ 8Ch x 30fps |
Recording Resolution Rate |
| Manual / Timer / Motion Detection / Smart Event |
Record Mode |
| 1Ch 4K@30fps, 2Ch 4MP@30fps, 4Ch 1080P@30fps, 8Ch 720P@30fps |
Local Sync Playback |
| 1080P (1920x1080) @ 120fps |
Decode Capability |
| Yes |
Remote Sync Playback |
| All, Timing Video, Motion Detection, Tag Search, Smart Event, Picture, Log |
Search Mode |
| Play, Pause, Fast Forward, Rewind, Previous Frame, Next Frame, Electronic Zoom, Clip, Audio |
Playback Functions |
| USB Device / Network |
Backup Mode |
| 1x RJ45 10M/100M (self-adaptive ethernet interface) |
Network Interface |
Incoming: 72Mbps
Outgoing: 48Mbps |
Bandwidth |
| IPv6 / TCP / IP, HTTP, HTTPS, UPnP, DNS, NTP, SMTP, DHCP, FTP, DDNS, RTSP, RTCP, p2p, PPPoE |
Network Protocols |
| Profile S, Profile T |
ONVIF |
| Edge, IE8-11, Google Chrome, Firefox, Safari |
Web Browser |
| Support Windows 7 / Windows 8 / Windows 10 / Windows 11 / Mac OS |
CMS Software |
| Yes |
Cloud Support |
| iPhone, Android |
Smartphone |
| 4x Independent 100Mbps PoE Network Interfaces (Output power AT mode 30W per port), 45/78 line order, Total Power Output≤ 45W, Support Plug and Play, Support network cable extended mode Max. 200m |
PoE |
1x SATA Hard Disk Interface (3.5" SATA)
Capacity: Up to 8TB |
Storage |
| 2x USB2.0 |
USB Interface |
| DC 48V / 1.36A ≤ 6W (Without Hard Disk and PoE) |
Power Consumption |
| 10°C ~ 50°C, 10%~90% (humidity)- |
Working Environment |
| 200x175x40 mm |
Dimension |
| 1.5kg |
Net Weight (Without HDD) |
